Description
Description
Model:
Magnum Nomad
Body Position:
Upright
Rider Recommendations:
This is a large frame with large wheels/tires.
Electric Bike Class:
Throttle On-demand (Class 2), Speed Pedelec (Class 3)
*Throttle can be removed for Class 1
Warranty:
1 Year Comprehensive
Max Load:
260
ELECTRONIC DETAILS
Motor Type:
Bafang Rear Hub
Motor Output:
48v 750W Nominal
Battery Voltage / Amp Hours / Watt Hours:
48v / 17.5Ah / 840Wh
Estimated Charge Time:
8.5 Hrs
Estimated Min And Max Range:
35-65 Miles (Depending On Riding Style, Terrain, Rider Weight and Pedal Assist Level.)
Display Type:
LCD Display
Display Readouts:
Speed, Trip, Trip Time, Time, ODO, Power output, PAS, Battery Level
Drive Modes:
Cadence Sensing Pedal Assist, Twist Throttle
Top Speed:
Up to 28mph With Pedal Assist, 20mph Throttle Only
Lights:
Front and Rear Integrated
BICYCLE DETAILS
Total Weight:
74lbs
Battery Weight:
9lbs
Frame Type:
Low Step with semi-integrated battery
Frame Material:
Aluminum
Fork Details:
Suspension Fork with Lockout
Gearing Details:
7 Speed Shimano
Shifter Details:
7 Speed Shimano
Cranks:
52T 170mm
Pedals:
Welgo Platform
Stem / Handlebar:
Promax Adjustable
Brake Details:
Hydraulic Disc Brakes
Grips:
Leather Ergo
Saddle:
Comfort
Seatpost / Seatpost Dimensions:
Promax 30.4mm
Fenders:
Front and Rear
Rims:
26 x 80mm 36h
Tires:
26″ x 4″
Wheel Size:
26″ X 4″
