Description
The Level 4 REC builds on Aventon’s legacy as a trusted, accessible commuter option, pairing a 750W hub motor with up to 75 miles of range for dependable, all-weather transportation. It’s built for riders who value simplicity, confidence, and everyday utility, offering strong acceleration for city streets, comfortable suspension for longer rides, and intuitive connectivity for security and peace of mind.
General Info
Weight: 68.5 lbs
Total Weight Limit: 300 lbs
Rider Height:
Regular: 4’11″–5’7″
Large: 5’7″–6’1″
Ebike Class: Class 2 (Convertible to Class 3)
Water Resistance:
Bike: IPX5
Components: IPX6
Range: Up to 75 miles
Safety Certifications: UL 2849
Battery Safety Certifications: UL 2271
Technical Overview
Frameset
Frame: 6061 Aluminum
Fork: 80mm travel, adjustable coil spring with preload adjustment and lockout, nutted axle
Rear Spacing: 148mm
Fork Spacing: 100mm
Wheelset
Front Wheel: 27.5″ double wall aluminum, 36 hole, 15x100mm thru axle
Rear Wheel: 27.5″ double wall aluminum, 750W nutted axle hub motor
Tires: Kenda Kwick Seven-5 Sport 27.5″ x 2.2″
Ebike System
Motor: Hub motor, 80Nm (96Nm boost), 1188W peak (1440W boost)
Motor Torque: 80Nm
Motor Power: 750W (1188W peak)
Display: Aventon A280
Battery: Removable internal lithium-ion, 36V, 20Ah, 733Wh (LG 21700 cells)
Battery Weight: 8.7 lbs
Controller: 36V, 33A
Throttle: Included
Sensors: Cadence & torque (sensor switch compatible)
Charger: 42V 4A
Charging Time: ~5 hours (0–100%)
Lights: Integrated front and rear
Smart Features
Regenerative braking
Ride Tune
4G / GPS
Unusual activity detection
E-lock
Hold mode
Remote notifications
Brakes
Rear Brake: Tektro HD-E3520 2-piston hydraulic disc with e-cutoff
Front Rotor: 180mm, 6-bolt
Rear Rotor: 180mm, 6-bolt
Additional: Regenerative braking
Drivetrain
Rear Derailleur: Shimano Altus RD-M310
Shifter: Shimano 8-speed trigger
Chain: 7/8 speed, 120L
Cassette: Shimano CS-HG200-8, 12–32T
Chainring: 48T
Crankset: 165mm
Bottom Bracket: Square tapered, sealed, double-sided torque sensor (83mm x 158.5mm)
Pedals: 9/16″ composite platform
Cockpit
Saddle: Aventon saddle
Seatpost: 30.9mm suspension seatpost with 50mm travel
Seatpost Clamp: 34.9mm
Handlebars: Aluminum 31.8mm, 680mm
Stem: Aluminum, 31.8mm clamp, 60mm length, 90° adjustable with internal routing
Grips: Aventon lock-on grips
Included Accessories
Rear rack
Fenders
Integrated lights
